Homogenizer gauges DS 4” (100mm)
These instruments are designed for homogenizer machines and are built according to standard n. 74-06 of 3-A organization (Sanitary Standards Symbol Administrative Council). The absence of interstices and the mirror finishing of the components assure the best hygiene. The process connection is a special diaphragm seal integrally built with the pressure gauge. To reduce the effects of severe operating conditions like vibrations and pulsations, the instruments can be liquid filled.
- Industrial sector: Food, Pharmaceutical, Machine building (OEM), Sanitary
- Instrument type: Bourdon tube pressure gauges
- Specific applications: Crystallizzing fluids, Viscous fluids, High pressure, Fluctuating pressure, Sedimentous fluids, Vibrations
- Conformity: EN 837 standard, 3A, Directive ATEX 2014/34/UE, EAC Conformity
- Accuracy: 1,6 of FSV
- Function: Local indication
- Material: All Stainless steel
- Range: 0...160 / 0...1600bar
- Protection degree: IP 67
- Working pressure: 75% of FSV
